Druid Relay Expansion Card

The Druid Relay Expansion Card can be used to increase the number of information outputs from the Druid 25LCD or Druid 28LCD energizers, and can be installed in the energizer housing. It has four inputs which can be used to switch the individual zones on/off and to switch between high and low voltage for each zone.

Installer Manual
User Manual

Features:

  • 4 digital inputs
  • 10 relay outputs
  • Robust surge protection is included on all inputs and outputs
  • All relays can be individually configured to be independent dry contacts or common-ground wet contacts with 12V nominal output
  • 3 programmed settings to choose from
  • Low battery indicator
  • Zone 1 and 2 alarms and fence check alarms
  • Service and tamper conditions
  • Communication timeouts

Specifications:

Weight 0.23 kg
Size

L180mm x W112mm x H22mm

Weight

~260g

Power supply

10V – 15Vdc

Stock CodeDescription
EE-LCD2X/RELDruid Relay Expansion Card
