Wizord 2i Energizer

The Wizord energizers have been field tested for many years and boast unsurpassed reliability. Simple to install and easy to maintain.

Installer Manual Wizord 2i
User Manual Wizord 2
Test report Wizord 2, 4 and Merlin 4
Specifications Energizers
CE Certificate Wizord 2

Features:

  • 2 Joule output energy (single zone)
  • Robust and flexible design for home security
  • Built-in alarm monitors tampering or faults on the high voltage and earth fence wires
  • Connectable to armed response radio or GSM module
  • Lightning and power surge protection
  • Intelligent power saving to extend battery life
  • Easy-to-use tag included for controlling the energizer
  • Powered by 240V mains and includes built-in battery for back-up power
  • Built-in gate alarm input to monitor if the gate is open or closed

Specifications:

Weight 5.908 kg
Enclosure size

285(L) x 212(W) x 120(D)mm

Weight

3.1kg excluding battery (7AH)
5.3kg including battery (7AH)

IP rating

IPx4

Operating temperature

-10°C to 50°C

Operating humidity

< 80% non-condensing

Electrical supply voltage

240V

Typical power consumption

17VA (normal operating conditions)

Standby Time

24hrs (fully charged battery)

Energy output

2.0 Joule (500 Ohms load)

Open circuit voltage

7400V

Stock CodeDescription
E-WIZ2IWizord 2i Energizer
